PRODUCT INFORMATION

• Suitable for raw material mixing in similar size and proportion of granule
• Suitable for material surface dewatering model
• Suitable for drying equipment of water ring cutting, underwater pelletizing and plastic recycling in extrusion process
• Various functions: Hot air drying, contact thermal conductivity drying and mixing
• Dry mixing range: 500 ~ 2000kg (Customized design and manufacture are available)
• Specification

• Model	Feed-In Capacity (L/hr)	Dry Mixing Weight	HP (Blower)	Electricity Heat	Dimension(L×W×H)
  TY-VDM500	830 L	500 kg	3HP (1/2HP×2)	14Kw	1100 mm × 860 mm × 2100 mm
  TY-VDM1000	1680 L	1000 kg	5HP(1/2HP×2) or(1/2HP×4)	16Kw (28Kw)	1280 mm × 990 mm × 2240 mm
  TY-VDM1500	2500 L	1500 kg	5HP(1/2HP×2) or(1/2HP×4)	16Kw (28Kw)	1580 mm × 990 mm × 2400 mm
  TY-VDM2000	3400 L	2000 kg	7.5HP (1/2HP×2) or(1/2HP×4)	18Kw (32Kw)	1600 mm × 1250 mm × 2400 mm

• ※　Specification and design are subject to change without prior notice. Please contact us if you have any question.
